Product Details:
|
| Regeneration: | 0.25-10 Hz | Agreement: | NMEA-0183 Compliant Protocol Or Custom Protocol |
|---|---|---|---|
| Port: | UART/12C/SPI | Chip: | M10050 |
| Sensitivity: | Tracking: -167dbm Capture: -160dbm Cold Start -148dbm | Start-up Time: | Cold Start：Average 29seconds Warm Start: 28 Hot Start： 1Seconds On Average |
| Voltage: | 1.8~3.3V | Max Acceleration: | ≦ 4G |
| Highlight: | -167dbm Tracking Senstivity GPS module,NMEA-0183 Compliant GPS module,M10050 Chip GPS module |
||
With a voltage range of 1.8~3.3V, this GPS module is designed to be highly efficient and low power. This makes it an ideal choice for battery-powered devices where power consumption is a critical factor.
In addition to its low power requirements, this GPS module is also designed to operate in a wide range of environmental conditions. The module is capable of operating in humid conditions, with a humidity range of 5% to 95% non-condensing. This makes it a reliable choice for outdoor applications where exposure to the elements is a concern.
One of the standout features of this GPS module is its available baud rate. With a range of 4800bps to 921600bps (default 38400bps), this module is capable of transmitting data quickly and efficiently. This makes it an ideal choice for applications where real-time location tracking is a must.
Another important feature of this GPS module is its regeneration rate. The module is capable of regenerating location data at a rate of 0.25-10 Hz, depending on the application requirements. This allows for accurate and reliable location tracking in a wide range of scenarios.
Overall, this GPS module is an excellent choice for anyone in need of a high-performance location tracking module. Whether you're building a device for personal or commercial use, this locating module is sure to meet your needs.
| Product Name | Location Tracking Module |
| Model Number | WT-62-M10 |
| Agreement | NMEA-0183 Compliant Protocol Or Custom Protocol |
| Voltage | 1.8~3.3V |
| Storage Temperature | -40℃ To 85℃ |
| Available Baud Rate | 4800bps~921600bps(default 38400bps) |
| Power Consume | Maximum Performance: Capture :25mA, Tracking (power Saving Mode /1HZ) : 5mA |
| Positioning Mode | A-GNSS |
| Sensitivity | Tracking: -167dbm Capture: -160dbm Cold Start -148dbm |
| Max Acceleration | ≦ 4G |
| Start-up Time | Cold Start:Average 29seconds Warm Start: 28 Hot Start: 1Seconds On Average |
The WT-62-M10 GPS Positioning Module is manufactured in China and has a supply ability of 10000 pcs/day. The product is shipped in a carton box and has a delivery time of 5-8 working days. Payment can be made through T/T, AliPay, or PayPal.
This GPS module has a wide range of baud rates available from 4800bps to 921600bps with the default set at 38400bps. It has a maximum height of 18000 M and a regeneration of 0.25-10 Hz. The module can operate at a voltage of 1.8~3.3V. It has a humidity range of 5% to 95% non-condensing.
The OTW WT-62-M10 GPS Positioning Module can be used in various application occasions and scenarios. It can be used in vehicle tracking systems, personal navigation devices, and mobile devices such as smartphones and tablets. It can also be used in geocaching, precision agriculture, and surveying and mapping.
In summary, the OTW WT-62-M10 GPS Positioning Module is a versatile and cost-effective GPS module that can be used in various scenarios. Its affordability, reliability, and wide range of baud rates make it an excellent choice for anyone looking for a GPS module.
